JET 40" X 20 GAUGE 3-IN-1 MACHINE, STK#756041, MODEL#SBR-40M **NEW**


Specific Info On This Equipment



Reference Number: 8061

Condition: New


"If you need a machine and don't buy it, then you will ultimately find you have paid for it but don't have it."   Henry Ford

Full Product Description

Model:  SBR-40M
Stock Number:  756041
Style (Type):  Combination
Mild Steel Capacity (Gauge):  20
Shearing Capacity (Gauge):  20
Bending Capacity (Gauge):  20
Rolling Capacity (Gauge):  20
Size of Slip Roll (L x Dia.) (in.):  40 x 1-5/8
Width of Upper Dies (in.):  1, 2, 2, 4, 6, 7,8, 12
Upper Die Height (in.):  4-3/4
Minimum Forming Radius (in.):  1
Wire Grooves (in.):  1/8, 3/16, 1/4
Base Dimensions (L x W x H) (in.):  16-1/2 x 43
Overall Dimensions (L x W x H) (in.):  56 x 23 x 30
Weight (lbs.):  575


JET innovation allows machine shop professionals the ability
to perform several vital tasks with a single compact
machine. The Combination Shear, Brake and Roll handles the
jobs of three separate machines, adding tremendous
versatility to your metal forming operation, without
crowding the shop floor. This high-quality triple threat is
backed by the JET industry leading Two Year Warranty


FEATURES:
* COMBINATION SHEAR, BRAKE AND ROLL
* Combination shear, brake and roll in one compact machine
* Right or left hand operation
* Shear can be used for mild steel, aluminum, brass,
copper, lead, plastic and zinc
* Brake is equipped with easily removable fingers that
permit angle, channel, box and other complex bending
operations
* Slip rolls are precision turned and ground with wire
grooves

STANDARD EQUIPMENT:
* Set of male dies
* One set of female dies
* Spring-loaded work hold down
* Back gauge
* Dual edge shear blade


2-YEAR FACTORY WARRANTY INCLUDED!!
